GEM-5 Array-Case

2017/11/14

GEM-5 Array Data Examples

An example Q-sum data obtained by painting the screen over the Geophex UXO Test Site, a 10 m x 10 m area, indicated by the white square boundaries. The ground truth shown on the right shows a total of 20 seeded targets of various metal pipes and one magnetic rock (red circle to the left). The seven parallel lines indicate the ground track of the GEM- 5 array having seven receiver channels; the swath is about 2-m wide.
